Place of Origin:
China
Brand Name:
Promega
Certification:
CE
Model Number:
Pro-CNC-1325
Contact Us
Advantage
1. Adopt linear square guideway which can adjustable gap and can change track, the life can be not less than 10 years,Comprehensive performance is the best
2. Cast iron platform with the box structure to ensure high rigidity, high precision
3. High performance ,high power spindle motor, low noise,strong cutting
4. Compatible Type3/Artcam/Castmate/Proe/CAXA / Wentai and other software.
5. Have power restored, power outagers continued carving, processing time forecast and other functions, the real human design.
Applicable industry
It is widely used in furniture processing , home decoration, woodworking decoration, wooden arts and carfts, stone carving processing etc.. industries the machine is used for large areas single-body,end milling, 3D relief, cutting production etc..
Technical parameters
| model | Pro-cnc-1325 |
| XYZ-axis travel | 1200x2500x200mm |
| Guide Rail | Circular guide rail |
| Maximum speed | 2800mm/min |
| Max engraving speed | 2000mm/min |
| Max feeding height | 200mm |
| Resolution | 0.005mm |
| Repeat positioning accuracy | 0.05mm |
| Operation system | Windos 2000/xp |
| Volate | 380v/220v/110v |
| Spindle power | 1.5kw~6kw |
| Spindle speed | 0~24000rpm/min |
| Motor | Stepper motor/ Servo motor |
| Package size | 3200*1840*1900mm |
| Control system | Ncstudio/DSP |
| Optional accessories | Cyclinder rotary attachment/dust collector/metal water tank |
