Place of Origin:
CHINA
Brand Name:
PM
Model Number:
1000
Contact Us
Double Sided Tape Machine
Semi-Automatic double sided tape applicator machine will reduce the time spends handing products which are folders, boxes, displays, stands etc.
The machine can apply the double sided tape to all the material which is with good hardness and flatness similar as Paper, Cardboard, Corrugated board, Wooden, PVC and the others. The thinnest paper 100 g/m2 upto 20 mm thickness wooden.
The machine has a PLC touch screen and PLC programs that enables you to program and saves a multitude of tasks related to the handling of different products.The tape applicator head adopts magnet valve and air cylinder working. The tape applicator head quantity can be installed 1-2 as optional.
Application:
The machine often to be used for poster, it can tape four tapes on the corner of poster. And then people can adhere the poster to wall of market.
Main performance and features:
1.Used for applying the double sided tape ,sealing tape and PVC tape on the envelope ,A4 paper ,carton box ,PVC material,decoration material and so on .
2.It is widely used in building materials, packaging, printing and many other industries
3.Instead of manual operation,and saving the labor force.
4.It is light and flexible,convenient to move, PLC programming, touching screen, operation simple.
5.With an adjustable feeding table and ability to load sheets up to 70x100cm it is the perfect machine for small scale work.
Product Paramenters
|
Model |
TMM 1000 |
|
Product width |
25mm (1") upto 1000mm (39") |
| Product materials | Envelope ,A4 paper ,carton box ,PVC, floor board,and the others |
| Product Thickness (Min paper grammage) | 100 g/m2 (for paper) |
| Product Thickness (The other material) | 0.1mm upto 20mm (0.8") (Such as floor board ,Corrugated board ) |
| Applicator Heads standard/max | 1 upto 4 Heads |
| Max number of spots | 4 spots (8 spots can be customized) |
| Min spot length/ Min tape strip length |
25 mm (1") |
| tape thickness |
0.1 mm - 2 mm |
| Tape width (max) | 5mm(0.2") upto 30mm(1.2") |
