Laser Cutting Machine With 1000/1500/2200W Fast Flow Generator 1.8M/Min Speed For Dieboard Making
Laser cutting machine product series:
Laser cutting machine detailed configuration and parameters
1. The machine tool adopts a gantry structure design, which makes the machine tool more stable and reliable, and has a small size.
2. Metal and non-metal automatic switching laser cutting machine, truly realize one machine for multiple uses.
3. Using precision ball screw and linear guide as transmission elements, high accuracy, fast speed, maximum running speed (no load) 24m / min, positioning accuracy ± 0.03mm / m, repeat positioning accuracy ± 0.01mm.
4. Using PA laser special numerical control system, combining the laser and the machine tool control system into one. With the development of HMI, CNC, and PLC, according to the most advanced method in the world, using WINDOWS as the operating platform, independently developed laser-oriented cutting The machine's operating system integrates laser cutting proprietary energy control functions, machine operation functions, laser operation functions, expert cutting process library, remote diagnosis and other functions.
5. Equipped with dedicated CAD / CAM automatic programming and automatic nesting software, which is convenient for drawing and programming in production, and saves raw materials to the maximum extent, and customizes special functions of the cutting process.
6. Simultaneous dust removal system for the upper and lower areas is adopted. The cutting waste is dropped from the hopper into the waste car, which is convenient for the operator to clean it regularly.
Laser cutting machine model:HY-2512-S2200
max. cutting size
X and Y axis position accuracy
|X and Y position repeat accuracy
|Table max. moving speed
|Fixed gantry type machine, mixed light structure
|Precision ball screw + linear guide
|Fully enclosed protection of the cutting area
With comprehensive safety interlock protection
Imported from Germany (not Hans laser’s made in China)
Cutting head crash protection
|Protect the Z-axis mechanism
|Exhaust smoke and dust
|Scrap collection trolley
|Electric control cabinet is sealed against dust and moisture
|Work area lighting
|Work warning ribbon
|General software and hardware interfaces are reserved for subsequent intelligent production
Laser installation method
Interspersed welding, the whole furnace annealing.
German PA laser high-performance CNC system
(1)with 15 ″ color flat display
(2)Internal distance adjustment function
(3)Adaptive read-ahead function
(4)Advanced adaptive adjustment technology
(5)Laser energy control function
|Precision ground screw
|Japan THK rail lubrication and seal protection system
|Japan THK Precision Linear Ball Guide
Japan NSK Precision Thrust Angle Bearings
|Laser cutting head
|Independent design with special function to extend the life of focusing lens
Imported SMC, Airtac
(1)Pressure reducing valve
(2)Throttle valve, check valve, ball valve
(6)Three major pieces of pneumatic
Three gas automatic conversion systems, directly controlled by the process library, high pressure cutting system
1) The internal structure of the DH-2200W industrial CO2 laser is more compact and small in size, which facilitates the installation of the whole machine.
2) The imported Roots pump has the advantages of small size, stable performance, perfect protection system and can work at higher frequencies.
3) Unique all-digital technology switching power supply excitation, high efficiency, small size, small internal consumption, no water cooling, power saving, and low operating cost. Modular switching power supply design, oil-immersed protection for high voltage part. Very good solution to insulation problems. Each channel can work independently in control.
4) The resonant cavity support frame produced by the introduction of German company technology has good stability and no hidden dangers of high-pressure sparks. It is not necessary to align the discharge tubes and electrodes for maintenance and replacement.
5) The advanced gas unit is used to automatically adjust the amount of the mixed gas through the power and then flow into the buffer area and then enter the cavity. Have fast charge, fast pumping and solar terms.
6) Excellent thermal stability The design of the resonant cavity protects all the lenses in the cavity, making the lens longer in service life and ensuring laser power and mode stability. In addition, the cavity has a simple structure, easy alignment, and a high safety factor.
|Rated output power
|Output power Max.
|Output power stability
|Continuous wave output power adjustable range
|TEM10* 45 ° linear polarization to the horizontal plane
|Adjustable range of pulse frequency
|Pulse width adjustable range
|AC 380V±5%, 50Hz 3phase,ground, 18KVA
The minimum temperature must be above the dew point
Maximum water hardness: 15 degrees (German standard)
Reduced gas consumption if output power is reduced
|External working interface of laser working status and power external control system
|Digital switching signal
|Output power external control
|0-10V Analog signal
|Same light path indication
|Way of working
Training and Technical service
Warranty: 1 year
During the warranty period, if the contract product is damaged or cannot operate normally due to our manufacturing processes and materials, we will be responsible for repairing the contract product for free. The warranty period is 12 months from the date of final acceptance of the contract product or 13 months from the date of shipment (first come first served).Consumables (optical devices, safety blocks, ceramic bodies, cutting tips, lubricants, etc.) are normal consumables in daily work, regardless of the warranty period.
The above price does not include international shipping costs and international tickets for technicians. If the laser tube needs to be replaced during the one-year warranty of the entire machine, we are responsible for domestic shipping costs, and international shipping costs are paid by the customer.
HY-2512-S1000/1500/2200 Basic components:
Main machine part: one machine tool and one laser generator
a laser chiller,
a set of suction fans and pipes,
a set of precision filters,
a set of two-dimensional laser adjustment frames,
a set of external light guide systems,
a 75 kW regulator set and other small accessories
Laser key components list (TOP GRADE)
|Resonant cavity adjustment end plate
|Squirrel cage fan
|Lens and Mirror
|Switching power supply
