Product Details:
|
| Processing Area: | 150x150mm Or 300x300mm | Laser Type: | CO2 |
|---|---|---|---|
| Laser Wave Length: | 1064nm | Power Stability: | (8h)<1%rms |
| Pulse Repetition Frequency: | <50KHz | Quality Of Laser Beam: | M2<8(@25A) |
| Focusing Lens: | Standard F160 | Smallest Marking Character: | 0.3mm |
| Minimum Marking Line Width: | 50um | Electricity Needs: | 220V 50Hz 30A |
| Total Power: | <1.5KW | Cooling Method: | Air Ccoling |
| Graphic File Format Supported: | PLT,AI,CDR,DWG,DXF,BMP,JPEG | ||
| High Light: | Laser Cutter Machine,Co2 Laser Marking Machine |
||
Applicable Industry
It can be widely used in the garments, leather, plexiglass, acrylic, plastic, wood, bamboo, wool, rubber, electric applicance, glass, button, wood and bamboo ware industries.
Description
High speed of processing, is 2-3 times faster than the traditional marking machine and long hours lifespan, small volume, suitable to poor working condition
Powerful marking software, compatible with files from corel draw, autoCAD, photoshop etc software; Support PLT, PCX, DXF, BMP and so on. It can directly use SHX and TTF word stock; Support the automatic coding, serial number, batch number, date printing and bar code, two dimensional barcode, automatic jump.
Applicable materials
Garments, leather, plexiglass, acrylic, plastic, wood, bamboo, wool, rubber, synthetic stuff.
Main configuration
Original Imported Laser Mirror Component
Simple 2d Operation Plaform
High Performance Signal Control Box
Sample Display
