0.3M/Min CO2 Laser Cutting Machine For 21MM Dieboard Making
CO2 Laser Cutting Machine 0.3M/Min
,21MM Die Board Laser Cutting Machine
,CO2 Laser Engraving Cutting Machine
Model: PM 1218
Laser Power GSI 200W or China 300W
Worktable size, 1250mm* 1850mm
Cutting Capacity
Die-borad,18 -20mm; Mild steel ≤ 3 mm; Stainless steel, ≤ 2 mm
Special characteristics of the product
High quality ball screw& linear guide transmission system
Imported Taiwan servo system
Auto-focusing system
Special smoke ventilation system that effectively remove smokes and dusts.
Scientific assembly to insure machine high precision and performance.
Machine mainly movement parts made by Cast-aluminum, to insure machine working at high speed and stable.
Light-duty design, save floor space.
Applicable Materials
Plywood, Acrylic, PVC, Steel sheet, etc
Applicable Techniques
Box, lable, electronic borad, carton, cards, etc.
Parameters
| Model | PM 1218 |
| Laser output power | 200W 300w |
| X-axis path | 1250mm |
| YY-axis path | 1850mm |
| Positioning Precision | ± 0.05mm/m |
| Max.speed of position | 10m/min |
| Control system | NC /motion card/cn |
| Transmission system | Ball-screw&linear guide |
| Driving system | 3 axial servo |
| Optical system | semi-flying-optical |
| Moving structure | gantry |
| Chiller system | special chiller system for imported laser tube |
| Overall dimensions | 3850mm× 220 0mm× 1400 mm |
| Overall Weight | 1500KG |
| Structure | open |
| Power supply | 380V/50HZ/ 60A |
-
